Name: China H05V2V2-F PVC Flexible Installation Cable Manufacturers Suppliers Factory - Huayu Cable
Brand: Huayu Cable
SKU: 309950500

Yangzhou Huayu Cable Co., Ltd. is one of the leading manufacturers and suppliers of h05v2v2-f pvc flexible installation cable in China. If you're going to wholesale CE approved h05v2v2-f pvc flexible installation cable, welcome to get free sample from our factory. All customized cables are with high quality and low price.

Product Description

H05VVH2-F is Compliant with EN 50525-2-11 standard, 300/500V heat-resistant PVC insulated and sheathed multi-core flexible cable; using 5-class multi-strand copper conductors, with a long-term allowable working temperature of 90℃, excellent flexibility; suitable for indoor dry or slightly humid environments, and low mechanical stress conditions, used as internal connection lines and power lines for high-temperature household appliances, lighting fixtures, and lightweight mobile equipment.

Application

H05V2V2-F is an EU standard 300/500V heat-resistant PVC flexible cable. Its long-term working temperature is 90℃, and it has good flexibility. It is suitable for indoor dry or slightly humid environments with low mechanical stress. It is mostly used in high-temperature household appliances, lighting fixtures, office equipment, and lightweight mobile appliances. It can be used as an internal connection line and power lead for equipment, but it is not suitable for outdoor laying, long-term exposure to sunlight, or frequent dragging and heavy pressure.

Product Feature

Rated voltage	300/500V
Conductor	Class 5 Multi-strand Soft Braided Bare Copper Conductor
Insulation	PVC
Sheath	PVC
Shape	Round
Standard	EN 50525-2-11:2011
Normal working temperature	70°C

Packing & Delivery

We deliver bespoke professional packaging solutions encompassing standard cable reels, cartons and pallets to guarantee seamless product shipment. Every individual roll is affixed with complete specification markings to facilitate straightforward installation and application, while custom-tailored packaging options are offered to accommodate both ocean and air freight requirements.

FAQ

Q: Can it be used for frequent dragging and moving of electric tools?

A: Not suitable. It is only applicable in low mechanical stress conditions and cannot withstand pulling, pressing, or intense friction for a long time.

Q: Does it have flame-retardant properties?

A: The standard basic model does not have any specific flame-retardant requirements. If there is a need for flame retardancy, a custom flame-retardant model will be required.

Q: What is the main difference between H05VV-F and H05VV2V2-F?

A: The insulation and sheath materials are different. H05V2V2-F uses V2 heat-resistant PVC (90℃), which is suitable for equipment with higher temperatures; H05VV-F uses ordinary PVC (70℃), suitable for normal temperature scenarios.

Q: Can it be used outdoors in an open area?

A: Not recommended. V2 PVC is not resistant to ultraviolet rays and will age and crack over time with prolonged exposure to the sun. It is only suitable for indoor dry / slightly humid environments.

Q: Can it be used for electric tools that are frequently dragged and moved?

A: Not suitable. It is only applicable to low mechanical stress conditions and cannot withstand pulling, rolling, and intense friction for a long time.

Q: Can it be placed directly next to the heating component?

A: It is not recommended to place it directly next to the heat source. Space for heat dissipation should be reserved to prevent local overheating and accelerate aging.
